GJ8 12m dia 10m3h 6bar
Alfa Laval Gunclean Toftejorg tank cleaning machine. Alfa Laval (formerly Toftejorg Group, acquired since 2003) specializes in fully programmable ship tank cleaning machines with turbine-driven rotary technology. The Gunclean Toftejorg equipment is designed primarily as fixed installed systems in crude oil, product and chemical tankers as well as offshore applications. The A
Inspector Detail
▸
Common issues
- Turbine/gearbox wear from internal erosion causing erratic or stalled indexing
- Nozzle erosion increasing spray pattern spread and reducing cleaning effectiveness
- Shaft seal wear allowing leakage
- Deposit/scale buildup fouling the internal drive mechanism
- Indexing mechanism fouling causing the program cycle to hang or repeat
- Corrosion of housing and fasteners in the cargo tank atmosphere
Inspection checklist
- Visual inspection of the nozzle for erosion or bore enlargement
- Spray pattern/coverage check during a test cycle where accessible
- Shaft seal leakage check
- Gearbox/turbine drive function and indexing cycle time check
- Housing and mounting flange corrosion check
- Supply line strainer condition check
- Operating pressure and flow at the machine checked against design values
Service intervals
| Strainer cleaning | routine, before each tank cleaning operation |
| Nozzle inspection/wear check | every 6-12 months or per the maker's running-hour interval |
| Gearbox/turbine internal service | typically every 1-2 years or per the maker's running-hour interval - confirm against the maker's maintenance manual for this model |
| Shaft seal replacement | on condition/leakage, typically checked at annual service |
Typical wear limits
| Nozzle bore diameter | monitor for erosion-driven enlargement; replace once flow or pressure deviates materially from the maker's design curve for the stated 12 m coverage diameter - confirm against the maker's nozzle wear table |
| Indexing cycle time | compare against the maker's baseline cycle time for the program; significant drift indicates gearbox/turbine wear - confirm against commissioning data |
Ranges are typical for this design class. Always confirm against the manufacturer documentation for your serial number.
Critical spares
- Nozzle tips/inserts
- Shaft seal kit
- Gearbox/turbine drive internals
- Strainer element
Safety
- Tank cleaning machines operate inside cargo tanks - confined space entry procedures and gas-freeing apply before any internal access
- High-pressure water/chemical jet - never operate near personnel or with the machine partially withdrawn
- Static electricity risk during tank washing of hydrocarbon cargoes - bonding/earthing per tanker operating procedures
- A machine left running unattended can build unexpected pressure if the supply line is blocked
Class survey
Not usually a standalone class survey item, but forms part of the cargo tank cleaning/inerting arrangement reviewed under tanker-specific notations; class may check that fixed tank cleaning machines are correctly rated for the cargo and gas-freeing duty and that associated piping and valves are in good order.
Components & Design
Component data being added…
Technical Data
🤖 Ask about this model
One free question — answered like a marine engineer. No account needed.
Common failures & inspection points
Inspectors regularly check nozzles for wear marks, scratches, surface erosion and deformed openings. Nozzle blockages from sludge accumulation are the most frequent periodic maintenance task. Damaged nozzles must be replaced as a group.
Inspectors monitor for abnormal vibrations, temperature rise and irregular noise. Detached gear teeth and uneven disk distribution cause vibration problems. Inspection recommended every 200-300 operating hours; bearing replacement after 300-500 hours or at least every 3 years.
Inspectors check ball bearings for free rotation without contamination and damage. Sleeve bushings in gearbox frame must be checked: maximum diameter not exceeding 10.4 mm (bore not ovally deformed). Inspect all bearings and sealing rings every 6 months; replacement after 6,000 operating hours or every 3 years.
Inspectors check for oil leakage and contamination at seal points. The hysteresis coupling eliminates conventional speed-setting shafts and reduces leak points. All rubber seals should be replaced at each service inspection to ensure hygiene and performance. Moisture and contamination ingress leads to seal failure.
Inspectors test programming logic and valve control for correct 3D-indexed impact pattern. Check creep movement (vertical screw movement while horizontal rotation occurs) and progressive compression from coarse to fine over 8 cycles.
Inspectors verify IMO certification and crude oil wash-through approval. Toftejorg T-73 and 270FT Mark I are specifically designed for crude oil tankers. Check for corrosion/wear from crude oil exposure and verify valve seals under crude oil operating conditions.
Type-general inspection and maintenance points for this equipment category — not model-specific.
