Library› Safety & LSA› Fire Detection Systems› Smoke Detector› Autronica BG-301-EXIC
Autronica

BG-301-EXIC

Smoke Detector · Fire Detection Systems

Technical data from manufacturer or class sources · not yet verified by a person
Specifications

Technical data.verified

Every value below comes from the manufacturer datasheet or class-society record on file for this model.

Detection TechnologyTriple infrared sensors
CertificationEx ic for Zone 2 only
Target FiresCarbonaceous material combustion
Expected Alarm Time range11-15 sec🔖
Maximum number of detectors/loop units80🔖
Ratio L/R for the loop cable30 μH/Ω🔖
📄
Download datasheet (3 KB)
Manufacturer documentation

Images from manufacturer documentation.

Photos, drawings and page previews from this model’s datasheet or catalog.

AutroFlame BG-301-EXIC is an interactive triple IR Flame detector designed for fire alarm systems.

Applications

  • Fire safety in control panels

Features

  • Interactive
  • Triple IR technology
  • Intrinsically safe
  • Connected to Autrosafe Fire Alarm Control panel

Standards

  • IECEx NEM 11.0017X
Source: IECEx DNV 24.0013X Issue 0 | IECEx Certificates, p. 3
Autronica BG-301-EXIC – Drawing (f0dfdd96c316_S2-4 S. 3)
Drawing · f0dfdd96c316_S2-4 · S. 3
Autronica BG-301-EXIC – Page preview (f0dfdd96c316_S2-4 S. 2)
Page preview · f0dfdd96c316_S2-4 · S. 2
Source: Autronica BG-301-EXIC datasheet, p. 2
