Tokyo Keiki TG-5000 is a marine gyrocompass or electronic heading-reference unit. It is normally installed in the bridge electronics or navigation equipment space with heading outputs distributed to steering and navigation consumers. Its primary purpose is to provide a stabilized true-heading reference for navigation, radar, ECDIS, autopilot and other bridge systems. Compared with a magnetic compass, a gyrocompass does not depend on the Earth's magnetic field and requires electrical power, sensors and internal control electronics. For exact ratings, dimensions, settings, capacities, materials and variant-specific limits, refer to the manufacturer documentation for the exact figure.

Specifications

Technical data.reference — unverified

Do you have the manufacturer datasheet for this model? Send it with the enquiry form — we check it and name the source.

Settling time hr2
IMO CompliantYes
Follow up error deg0.1
Manufacturer documentation

Images from manufacturer documentation.

Photos, drawings and page previews from this model’s datasheet or catalog.

The Tokyo Keiki TG-5000 Gyro Compass is a high-quality navigation instrument that provides accurate heading information.

Features

  • Suspension wire floating method for improved accuracy
  • Electrical pick-off devices for enhanced accuracy
  • Shock absorbers to minimize vibration interference
  • Emergency power source for continuous operation
  • Speed-related error correction
Tokyo Keiki TG-5000 – Drawing (49b3b23c610b_S1-1 S. 1)
Drawing · 49b3b23c610b_S1-1 · S. 1
Tokyo Keiki TG-5000 – Drawing (cf36091315a8_S1-1 S. 1)
Drawing · cf36091315a8_S1-1 · S. 1
Source: Tokyo Keiki TG-5000 datasheet, p. 1
Service

Service notes.

What our service work and the manufacturer documentation say about keeping this model running.

Compare master and repeater headings with independent references and check alarm history, power supply, distribution interfaces and settling behaviour after restart. Verify heading delivery to all critical consumers. Any internal calibration or alignment should follow approved service procedures. Refer to manufacturer documentation for the exact figure for permissible errors and adjustment criteria.
