WAF 362

Regular maintenance is crucial to ensure the longevity and performance of marine propulsion gearboxes like the Reintjes WAF 362. This robust marine reduction gearbox is designed for applications requiring a rated power of 500 kW. The Reintjes WAF 362 features an integrated sump with a common operating pressure/lubrication oil line, ensuring efficient lubrication and reducing wear over time. Key areas to inspect include the tooth flanks for signs of pitting or spalling, which can be detected using an endoscope after removing inspection covers. Additionally, bearing damage should be visually inspected, particularly focusing on discolorations, scratches, and abnormal noises that indicate wear. The oil condition is another critical aspect; it should be sampled every six months to check for contamination, viscosity changes, or signs of combustion. For optimal performance, the hydraulic coupling must also be checked for wear, leaks, and pressure loss, with standard operating pressures ranging from 21 to 25 bar. Regular checks on shaft deflection and bearing load are essential to prevent misalignment and excessive wear. Finally, ensuring the casing remains leak-free and free from corrosion is vital for maintaining the integrity of the Reintjes WAF 362 gearbox.
