Häufige Probleme
- Fuel injection valve dripping or fouling causing cylinder liner scuffing or exhaust temperature deviation between units
- Exhaust valve burning or seat wear from sustained high thermal loading
- Piston ring and liner scuffing, particularly after periods of slow steaming or low-load operation
- Turbocharger fouling on the compressor or turbine side, reducing scavenge air pressure
- Crosshead bearing wear or white-metal damage if lubrication or alignment drifts out of tolerance
- Scavenge air cooler fouling, reducing charge air density and engine performance
- Common-rail fuel or servo oil system leaks affecting injection timing and pressure control
- Cylinder lubrication feed rate mismatched to load, causing under- or over-lubrication
Prüfliste
- Review indicator/PMI diagrams for cylinder-to-cylinder pressure balance
- Check exhaust gas temperature spread between cylinders against baseline
- Inspect fuel injection valves for dripping and spray pattern at scheduled intervals
- Check crosshead and main bearing clearances by bridge gauge measurement
- Borescope or visual inspection of piston crown, rings and liner through the scavenge ports
- Inspect turbocharger blading, bearings and general cleanliness
- Verify cylinder lubrication feed rate and timing against current load and fuel sulphur content
- Check scavenge air cooler differential pressure and condensate drains
- Inspect exhaust valve seat and spindle condition at overhaul
- Confirm crankcase oil mist detector alarm function
Wartungsintervalle
| Fuel injection valve overhaul | typically 8,000-12,000 running hours or per condition monitoring - confirm against WinGD's own instruction manual |
|---|
| Cylinder liner/piston major overhaul | typically in the order of 12,000-24,000 h depending on fuel quality and load profile |
|---|
| Turbocharger major overhaul | typically 12,000-16,000 h, with interim cleaning at shorter intervals |
|---|
| Crosshead/main bearing inspection | per Continuous Survey Machinery schedule or approved condition-based monitoring |
|---|
| Scavenge air cooler cleaning | typically every 4,000-8,000 h or per differential pressure trend |
|---|
| Cylinder lubricator calibration check | typically every 2,000-4,000 h |
|---|
Typische Verschleißgrenzen
| Piston ring gap | increases gradually with running hours; renewal is normally based on the maker's specific gap limit for this bore class rather than a generic figure - confirm against WinGD's instruction manual |
|---|
| Cylinder liner wear | assessed by bore gauging against the maker's renewal criteria for this engine - typical two-stroke practice uses a percentage-of-bore limit, but confirm the exact figure in the current limit book |
|---|
| Crosshead bearing clearance | use the engine's own instruction-book tolerance table; running clearances vary by build series and should not be generalised |
|---|
Die Bereiche sind für diese Bauklasse typisch. Maßgeblich sind stets die Herstellerunterlagen zur jeweiligen Seriennummer.
Kritische Ersatzteile
- Fuel injection valve (complete unit)
- Exhaust valve spindle and seat
- Piston ring set (per cylinder)
- Cylinder liner
- Crosshead bearing shells
- Turbocharger nozzle ring and bearing set
- Starting air valve
Sicherheit
- High-pressure common-rail fuel system - never work on rail or injection lines while pressurised
- Crankcase explosion risk after overheating events - oil mist detector alarms must never be bypassed
- Hot exhaust and turbocharger surfaces - check lagging integrity regularly
- Starting air system stored energy - isolate and vent before opening the starting air manifold
- Scavenge space fire risk from oil accumulation, especially after prolonged low-load running
Klassenbesichtigung
Normally enrolled in Continuous Survey Machinery (CSM) or an approved condition-based scheme; surveyors expect running-hours logs, overhaul records for crosshead/main bearings and turbochargers, and confirmation that crankcase explosion relief doors and oil mist detection are tested and functional.
Geschätzte Lebensdauer: Design life for the crankcase/frame is typically in the order of 25+ years of vessel service with continuous component-level overhauls; individual wearing parts (liners, rings, bearings, injection equipment) are replaced on running-hours and condition-based schedules rather than the engine having one fixed lifetime figure.
