Rated control circuit supply voltage US24 V DC
Control supply voltage range19.2 V DC ... 30 V DC
Rated control supply current IS40 mA
Type of protectionSurge protection
Rated actuating voltage UC24 V DC
Triggering voltage range19.2 V DC ... 30 V DC
Rated actuating current IC5 mA (Input type 1)
Typical turn-off time< 30 ms
Rated operating voltage Ue500 V AC
Operating voltage range42 V AC ... 550 V AC
Rated operating current Ie9 A (AC-51)
Mains frequency50/60 Hz
Load current range0 A ... 9 A (see to derating)
Leakage current0 mA
Switching frequency≤ 2 Hz (Load-dependent)
Maximum power dissipation7W
Minimum power dissipation0.88 W
Stripping length8 mm
Conductor cross section solid0.2 mm² ... 2.5 mm²
Conductor cross section flexible0.2 mm² ... 2.5 mm²
Conductor cross section AWG24 ... 14
Torque0.5 Nm ... 0.6 Nm
Ambient temperature (operation)-25 °C ... 70 °C (observe derating)
Ambient temperature (storage/transport)-40 °C ... 80 °C
Degree of protectionIP20
Width22.5 mm
Height106.6 mm
Depth113.7 mm
Fla6.5 A (500 V AC)
Rated insulation voltage500 V
Rated surge voltage6 kV
