Library› Electrical› Electrical Components & Switchgear› Protection Relay› DEIF TAS-331DG
DEIF

TAS-331DG

Protection Relay · Electrical Components & Switchgear

Class-certified type (DNV register) · technical data sheet not yet verified

Powerful, fast and compact, the TAS units in DEIF’s transducer range measure power or reactive power on a 1- or 3-phase AC network and provide output signal as direct current or voltage signal proportional to measurements for PLCs, PCs, microprocessor control, indicators, alarm units etc.

Specifications

Technical data.reference — unverified

Do you have the manufacturer datasheet for this model? Send it with the enquiry form — we check it and name the source.

Frequency range30…45…65…80 Hz
Measuring current (In)0.75/1.5/3.0/6.0 A
AccuracyClass 0.5
Operating temperature-25…70 °C
Degree of protectionIP40
Aux. supply voltage DC24-48-110-220 V DC
Manufacturer documentation

Images from manufacturer documentation.

Photos, drawings and page previews from this model’s datasheet or catalog.

The TAS-331DG is a power supply unit designed for marine applications.

Applications

  • Power supply

Features

  • Wide input voltage range
  • Overload protection
  • Short-circuit protection

Options

  • Configuration kit
  • Extra labels

Standards

  • IEC 688
  • DIN 40040
  • EN 61000-6-1/2/3/4
  • IEC 529
  • EN 60529
  • UL94
DEIF TAS-331DG – Drawing (245ccfc4bdf2_S4-8 S. 5)
Drawing · 245ccfc4bdf2_S4-8 · S. 5
DEIF TAS-331DG – Page preview (245ccfc4bdf2_S4-8 S. 4)
Page preview · 245ccfc4bdf2_S4-8 · S. 4
Source: DEIF TAS-331DG datasheet, p. 6
