Heinzmann GmbH & Co. KG

XIOS UC1, UC2

Engine Control Unit (ECU) · Engine Components

Class-certified type (DNV register) · technical data sheet not yet verified
270 × 240 × 48Dimensions
9 … 32Voltage

XIOS UC1, UC2 by Heinzmann GmbH & Co. KG. DNV TA certificate TAA00001ZX.

Specifications

Technical data.reference — unverified

Do you have the manufacturer datasheet for this model? Send it with the enquiry form — we check it and name the source.

Voltage9 … 32 VDC
Ambient temperature-40 … 85 °C
Dimensions270 × 240 × 48 mm
Protection gradeIP00, IP6K9K
Power consumption (at 24 VDC)350 mA
Processor264 MHz
Classification

DNV type approval

Verified against the DNV Approval Finder — the certificate below is issued by DNV, not by us.

CertificateTAA00001ZX
Open the certificate at DNV
