L16/24
L16/24 by CSSC Marine Power Zhenjiang Co., Ltd.. DNV TA certificate TAM00000S1.
Inspector Detail
▸
Common issues
- Water or particulate contamination of the hydraulic oil accelerating wear
- Internal vane/body seal leakage reducing available turning torque
- Air entrainment in the hydraulic circuit causing erratic or delayed rudder response
- Relief valve drift reducing available torque before it is noticed
- Loose or worn rudder stock/tiller coupling fasteners from continuous vibration
- Sticking isolating or bypass valves slowing or preventing changeover between pump units
- Rudder angle transmitter/feedback wear causing indication drift
Inspection checklist
- Hydraulic oil condition, level, and water content check
- Internal leakage test on each power unit during a changeover
- Rudder angle indication check against actual rudder position, local and bridge
- Relief valve set-pressure verification
- Full changeover and emergency/local steering control test
- Coupling bolts and keys at the rudder stock checked for tightness
- Isolating and bypass valve operation and seal-tightness check
- Steering gear alarms (power failure, overload, low oil) function test
- Communication between steering compartment and bridge tested
Service intervals
| Hydraulic oil sampling | typically every 3-6 months or per the maker's schedule |
| Departure steering test and pump changeover | each departure, per SOLAS requirements |
| Relief valve and alarm function test | annually or per class requirements |
| Internal inspection (vanes, seals, bearings) | typically every 2.5-5 years alongside the class steering gear survey |
Typical wear limits
| Vane seal internal leakage | renew when bypass exceeds the maker's stated limit at rated torque - confirm the exact figure against the equipment manual rather than a fixed number |
| Relief valve set-pressure drift | reset or renew if it drifts beyond a few percent of the nameplate setting |
Ranges are typical for this design class. Always confirm against the manufacturer documentation for your serial number.
Critical spares
- Vane/body seal kit
- Relief valve
- Coupling bolts and keys
- Isolating/non-return valve internals
- Rudder angle transmitter unit
Safety
- High-pressure hydraulic fluid injection risk at leaking joints or hoses
- Moving tiller and linkage present a crush hazard during testing - keep clear
- An undrilled emergency changeover procedure risks a real loss-of-steering casualty
- Confined space entry precautions apply to the steering gear compartment/tiller flat
Class survey
Surveyed at each Special/Class survey (typically 5-yearly) with intermediate checks; expect a documented changeover test between power units and confirmation that the emergency steering procedure is drilled and rudder angle indication is accurate. Keep the unit's type-approval documentation on board.
Components & Design
Component data being added…
Technical Data
🤖 Ask about this model
One free question — answered like a marine engineer. No account needed.
Suppliers & Spare Parts
Direct links to manufacturer, datasheet, spare-parts portal and dealers — request access below.
📄 Request sourcing links & documentsCases, daily reports, timesheets and AI troubleshooting in the OceanSphere Marine app — free for 14 days.
Start free trial →Find manufacturers, repair shops and spare-part dealers in the Maritime Network — our global company directory.
Maritime Network →DNV type approval
Verified against the DNV Approval Finder — the certificate below is issued by DNV, not by us.
- Certificate
- TAM00000S1
- Approved as
- Diesel Engine · Machinery Components
- Certificate holder
- CSSC Marine Power Zhenjiang Co., Ltd. (China)
- Valid until
- 2027-11-28
