Sika Services

Sikaflex®-296

Adhesives & Sealants · Marine Interior & Construction Materials

Technical data from manufacturer or class sources · not yet verified by a person​​‍‌​‌​⁠‍‌‌⁠⁠​​​⁠⁠‌⁠
Service temperature -40 to 90 °CCapacity
One-component polyurethaneMedium

Sikaflex-296 is a high-performance elastic gap-filling adhesive from Sika Services AG for direct glazing applications in the shipbuilding industry. The data sheet lists use for glass windows in OEM and repair marine markets, and describes it as resistant to ageing and weathering, solvent- and PVC-free, suitable for manual and pump application, and Wheelmark approved.

Specifications

Technical data.reference — unverified

Do you have the manufacturer datasheet for this model? Send it with the enquiry form — we check it and name the source.

Density (uncured)1.2 kg/l (10.0 lb/gal)
Application temperatureambient 10 ─ 35 °C (50 ─ 95 °F)
Skin time (CQP019-1)45 minutes A
Open time (CQP526-1)30 minutes A
Shore A hardness (CQP023-1 / ISO 48-4)45
Tensile strength (CQP036-1 / ISO 527)6 MPa (870 psi)
Elongation at break (CQP036-1 / ISO 527)450 %
Tear propagation resistance (CQP045-1 / ISO 34)14 N/mm (80 pli)
Tensile lap-shear strength (CQP046-1 / ISO 4587)4.5 MPa (650 psi)
Insulation resistance (CQP079-2 / DIN IEC 60167)108 Ω cm
Service temperature (CQP509-1 / CQP513-1)-40 ─ 90 °C (-40 ─ 194 °F)
Manufacturer documentation

Images from manufacturer documentation.

Photos, drawings and page previews from this model’s datasheet or catalog.

Sikaflex®-296 is a high performance elastic gap-filling adhesive designed for direct glazing applications in the shipbuilding industry.

Applications

  • glass windows
  • OEM and repair Marine markets

Features

  • Resistant to aging and weathering
  • Excellent working characteristics
  • Solvent- and PVC-free
  • Black primerless application possible
  • Suitable for manual and pump applications
  • Wheelmark approved
  • Tooled to a very fine finish
Sika Services Sikaflex®-296 – Photo (25a37bce4841_S1-2 S. 2)
Photo · 25a37bce4841_S1-2 · S. 2
Sika Services Sikaflex®-296 – Photo (25a37bce4841_S1-2 S. 2)
Photo · 25a37bce4841_S1-2 · S. 2
Sika Services Sikaflex®-296 – Photo (25a37bce4841_S1-2 S. 2)
Photo · 25a37bce4841_S1-2 · S. 2
Sika Services Sikaflex®-296 – Drawing (2445fc6536c8_S1-1 S. 1)
Drawing · 2445fc6536c8_S1-1 · S. 1
Sika Services Sikaflex®-296 – Drawing (25a37bce4841_S1-2 S. 2)
Drawing · 25a37bce4841_S1-2 · S. 2
Source: Sika Services Sikaflex®-296 datasheet, p. 1
Service

Service notes.

What our service work and the manufacturer documentation say about keeping this model running.

Follow the data sheet for surface preparation, primer, application and cure time before the window is loaded, and inspect bond lines for cracks, voids and water ingress during rounds. Confirm the approved product against the approval documents when windows are refitted.

Inspection

Common failures & inspection points

Spares

Replacement Parts

Spare parts notes

Keep unopened cartridges or sausages of the approved adhesive, primers, cleaners and application tools on board, stored within the stated shelf life.
