Library› Engine Room› Industrial Valves› Valve Actuator› emerson easy-Drive 200L
emerson

easy-Drive 200L

Valve Actuator · Industrial Valves

Class-certified type (DNV register) · technical data sheet not yet verified
Specifications

Technical data.reference — unverified

Material Temperature Capabilities(1)-20 to 70°C (-4 to 158°F)
Maximum Stroke Length19 mm (0.75 inch)
Maximum Thrust Force3336 N (750 lbf)
CertificationsImmunity: Industrial locations per table 2 of EN 61326-1 Standard. Performance is shown in table 2
Maximum Current Draw4 amps
Average Thrust2446 N / 550 lbf
Material Temperature CapabilitiesElectric Actuator Assembly: -20°C / -4°F to 70°C / 158°F
Idle Current Draw15 mA at 24 V DC, 25 mA at 12 V DC
Maximum Thrust3336 N / 750 lbf
Approximate Weight9.5 kg / 21 lbs
Power12/24 V DC
Manufacturer documentation

Images from manufacturer documentation.

Photos, drawings and page previews from this model’s datasheet or catalog.

Electric actuator for flow or pressure control with various control signals and safety certifications.

Applications

  • Flow control
  • Pressure control
  • Industrial applications

Features

  • Dry contact and Modbus RTU control signals
  • 4-20 mA positioning
  • Explosion-proof and flameproof certifications
  • Type 4X and IP66 enclosure
  • Meets EN 61326-1 electromagnetic compatibility standards

Options

  • RPU-100 reserve power unit for loss of power positioning

Standards

  • EN 61326-1 (2013)
emerson easy-Drive 200L – Photo (aafe99dcd440_S3-31 S. 6)
Photo · aafe99dcd440_S3-31 · S. 6
emerson easy-Drive 200L – Photo (aafe99dcd440_S3-31 S. 7)
Photo · aafe99dcd440_S3-31 · S. 7
emerson easy-Drive 200L – Photo (aafe99dcd440_S3-31 S. 8)
Photo · aafe99dcd440_S3-31 · S. 8
emerson easy-Drive 200L – Photo (aafe99dcd440_S3-31 S. 8)
Photo · aafe99dcd440_S3-31 · S. 8
emerson easy-Drive 200L – Photo (aafe99dcd440_S3-31 S. 9)
Photo · aafe99dcd440_S3-31 · S. 9
emerson easy-Drive 200L – Photo (aafe99dcd440_S3-31 S. 9)
Photo · aafe99dcd440_S3-31 · S. 9
emerson easy-Drive 200L – Photo (aafe99dcd440_S3-31 S. 10)
Photo · aafe99dcd440_S3-31 · S. 10
emerson easy-Drive 200L – Photo (aafe99dcd440_S3-31 S. 10)
Photo · aafe99dcd440_S3-31 · S. 10
Source: emerson easy-Drive 200L datasheet, p. 2
