Zenitel

HEP-1000-24

DC Power Supply · Electrical Components & Switchgear

Class-certified type (DNV register) · technical data sheet not yet verified
Specifications

Technical data.reference — unverified

Do you have the manufacturer datasheet for this model? Send it with the enquiry form — we check it and name the source.

BOOST CHARGE VOLTAGE Vboost28.8V
FLOAT CHARGE VOLTAGE Vfloat27.6V
RECOMMENDED BATTERY OUTPUT CAPACITY(AMP HOURS)(Note 2)120 ~ 350AH
OUTPUT CURRENT35A
VOLTAGE RANGE Note 390 ~ 305VAC, 250 ~ 431VDC
FREQUENCY RANGE47 ~ 63Hz
POWER FACTOR (Typ.)PF>0.99/115VAC, PF>0.95/230VAC, PF>0.93/277VAC at full load
INPUT EFFICIENCY (Typ.)95%
AC CURRENT (Typ.)10.1A / 115VAC
INRUSH CURRENT(Typ.)Cold start 40A at 230VAC
LEAKAGE CURRENT<0.75mA / 240VAC
AUXILIARY POWER12V @ 0.5A tolerance ±10%, ripple=150mVp-p
WORKING TEMP.-40 ~ +70℃
WORKING HUMIDITY20 ~ 95% RH non-condensing
DC VOLTAGE24V
RATED CURRENT42A
RATED POWER1008W
VOLTAGE ADJ. RANGE24 ~ 30V
VOLTAGE TOLERANCE±1.0%
LINE REGULATION±0.5%
LOAD REGULATION±0.5%
SETUP, RISE TIME1800ms, 80ms at full load
HOLD UP TIME (Typ.)16ms / 230VAC at 75% load
VOLTAGE RANGE90 ~ 305VAC
EFFICIENCY (Typ.)95%
OUTPUT VOLTAGE ADJUSTMENT50 ~ 125% of nominal output voltage
Output120 ~ 350AH
POWER FACTORPF>0.99/115VAC, PF>0.95/230VAC, PF>0.93/277VAC
Efficiency95%
AC CURRENT10.1A / 115VAC
INRUSH CURRENTCold start 40A at 230VAC
STORAGE TEMP., HUMIDITY-40 ~ +80℃, 10 ~ 95% RH non-condensing ℃, % RH
TEMP. COEFFICIENT±0.03%/℃ (0 ~ 50℃)
ISOLATION RESISTANCEI/P-O/P, I/P-FG,O/P-FG:100M Ohms/500VDC/25℃/ 70%RH
Manufacturer documentation

Images from manufacturer documentation.

Photos, drawings and page previews from this model’s datasheet or catalog.

“<0.75mA / 240VAC 105~125% rated current Protection type : Constant current limiting, shut down O/P voltage after 5 sec. After O/P voltage falls, re-power on to recover Constant current limiting, unit…”

Zenitel HEP-1000-24 – Drawing (a1455c9ade51_S31-104 S. 31)
Drawing · a1455c9ade51_S31-104 · S. 31
Zenitel HEP-1000-24 – Drawing (a1455c9ade51_S31-104 S. 32)
Drawing · a1455c9ade51_S31-104 · S. 32
Zenitel HEP-1000-24 – Drawing (a1455c9ade51_S31-104 S. 33)
Drawing · a1455c9ade51_S31-104 · S. 33
Zenitel HEP-1000-24 – Page preview (a1455c9ade51_S31-104 S. 34)
Page preview · a1455c9ade51_S31-104 · S. 34
Zenitel HEP-1000-24 – Page preview (a1455c9ade51_S31-104 S. 35)
Page preview · a1455c9ade51_S31-104 · S. 35
Zenitel HEP-1000-24 – Page preview (a1455c9ade51_S31-104 S. 36)
Page preview · a1455c9ade51_S31-104 · S. 36
Zenitel HEP-1000-24 – Page preview (a1455c9ade51_S31-104 S. 37)
Page preview · a1455c9ade51_S31-104 · S. 37
Source: zenitel HEP-1000-24 datasheet, p. 1
