Zenitel

RSP-1600-24

DC Power Supply · Electrical Components & Switchgear

Class-certified type (DNV register) · technical data sheet not yet verified
Specifications

Technical data.reference — unverified

Do you have the manufacturer datasheet for this model? Send it with the enquiry form — we check it and name the source.

DC VOLTAGE12V, 24V, 27V, 36V, 48V
RATED CURRENT125A, 67A, 59A, 44.5A, 33.5A
CURRENT RANGE0 ~ 125A, 0 ~ 67A, 0 ~ 59A, 0 ~ 44.5A, 0 ~ 33.5A
RATED POWER1500W, 1608W, 1593W, 1602W, 1608W
OUTPUT VOLTAGE ADJ. RANGE11.5 ~ 15V, 23.5 ~ 30V, 26.5 ~ 33.5V, 35.5 ~ 45V, 47.5 ~ 58.8V
VOLTAGE TOLERANCE±1.0%
LINE REGULATION±0.5%
LOAD REGULATION±0.5%
SETUP, RISE TIME1500ms, 60ms/230VAC at full load
HOLD UP TIME (Typ.)16ms / 230VAC at 75% load, 10ms / 230VAC at full load
VOLTAGE RANGE90 ~ 264VAC, 127 ~ 370VDC
FREQUENCY RANGE47 ~ 63Hz
POWER FACTOR (Typ.)0.97/230VAC at full load
EFFICIENCY (Typ.)89%, 91.5%, 92%, 92%, 93%
AC CURRENT (Typ.)14A/115VAC 8A/230VAC 15A/115VAC, 8.5A/230VAC
INRUSH CURRENT (Typ.)COLD START 35A/230VAC
LEAKAGE CURRENT<2mA / 230VAC
Output Voltage+24dc
Manufacturer documentation

Images from manufacturer documentation.

Photos, drawings and page previews from this model’s datasheet or catalog.

“89% 91.5% Note.5 14A/115VAC 8A/230VAC 15A/115VAC AC CURRENT (Typ.) COLD START 35A/230VAC INRUSH CURRENT (Typ.) EFFICIENCY (Typ.)”

Features

  • high efficiency
  • adjustable output voltage
  • adjustable output current
  • overvoltage protection
  • overtemperature protection
  • overload protection
Source: zenitel RSP-1600-24 datasheet, p. 2
Zenitel RSP-1600-24 – Drawing (1b7d0a9e1a2e_S50-123 S. 50)
Drawing · 1b7d0a9e1a2e_S50-123 · S. 50
Zenitel RSP-1600-24 – Drawing (1b7d0a9e1a2e_S50-123 S. 51)
Drawing · 1b7d0a9e1a2e_S50-123 · S. 51
Zenitel RSP-1600-24 – Drawing (1b7d0a9e1a2e_S50-123 S. 52)
Drawing · 1b7d0a9e1a2e_S50-123 · S. 52
Zenitel RSP-1600-24 – Page preview (1b7d0a9e1a2e_S50-123 S. 53)
Page preview · 1b7d0a9e1a2e_S50-123 · S. 53
Zenitel RSP-1600-24 – Page preview (1b7d0a9e1a2e_S50-123 S. 54)
Page preview · 1b7d0a9e1a2e_S50-123 · S. 54
Zenitel RSP-1600-24 – Page preview (1b7d0a9e1a2e_S50-123 S. 55)
Page preview · 1b7d0a9e1a2e_S50-123 · S. 55
Zenitel RSP-1600-24 – Page preview (1b7d0a9e1a2e_S50-123 S. 56)
Page preview · 1b7d0a9e1a2e_S50-123 · S. 56
Source: zenitel RSP-1600-24 datasheet, p. 1
