UNIKA

BFCU-XFR(c)

Instrumentation Cable · Cable & Wiring

Class-certified type (DNV register) · technical data sheet not yet verified
Specifications

Technical data.reference — unverified

Do you have the manufacturer datasheet for this model? Send it with the enquiry form — we check it and name the source.

Operating temperature90°C
Operating Voltage150/250(300)V
Manufacturer documentation

Images from manufacturer documentation.

Photos, drawings and page previews from this model’s datasheet or catalog.

Extended fire resistant, flame retardant, halogen-free instrumentation cable designed for fixed installations in EX and safe areas, emergency and critical systems where fire resistance is required.

Applications

  • Instrumentation systems
  • Communication systems
  • Control systems
  • Alarm systems

Features

  • Extended fire resistant properties
  • Mud resistant
  • Halogen-free
  • Low smoke
  • Flame retardant

Standards

  • NEK TS 606:2009
  • IEC 60092-376
  • IEC 60228
  • IEC 60092-360
  • IEC 60332-1-2
  • IEC 60332-3-22
  • IEC 60331-1, -2
  • EN 50200:2006 Annex E
UNIKA BFCU-XFR(c) – Drawing (e293ea932849_S1-1 S. 1)
Drawing · e293ea932849_S1-1 · S. 1
Source: UNIKA BFCU-XFR(c) datasheet, p. 1
